Product Introduction

Product Roadmap

For more information on new products and products under development, please click the link below.





New Products

DRS-240/480 Series

240W / 480W All-in-One Intelligent Security Power Supply

MEAN WELL DRS-240/480 Series DIN Rail Type All-in-One Intelligent Security Power Supply

The most attractive feature of DRS-240/480 is the multi-functional integration, which includes AC-DC power supply, battery charger, DC-UPS and communication monitor in a single compact package. Other outstanding features include 90~305Vac input applicable to all parts of the world, compliance with safety control regulations and alarm signals, and automatic load priority power balancing (the battery will be charged with excess power). Additionally, the product has built-in MODBus communication interface, and charging parameters can be adjusted via SBP-001. ....


DRC-180 Series

180W DIN Rail Type Security Power Supply

MEAN WELL DRC-180 Series 180W DIN Rail Type Security Power Supply

This product is suitable for installation in the TS-35/7.5 or TS-35/15 rails inside the power distribution box. Not only is the 90~264VAC voltage input applicable to all parts of the world, but also two models of 13.8VDC and 27.6VDC are planned for more customer selections. The DC output side is divided into the main output (CH1), which can be used for the load equipment and the auxiliary output (CH2), which can charge the battery at the same time. In addition, it also has AC OK, battery low voltage alarm, and can form a DC-UPS backup system with an external battery....


DUPS20/40 Series

20A/40A DIN Rail Type Uninterruptible DC-UPS Module

MEAN WELL 20A/40A DUPS20/40 Series DIN Rail Type Uninterruptible DC-UPS Module

In order to provide more cost-effective DC backup solutions, MEAN WELL has launched a new-generation DUPS20/40 series. The DC-UPS module is paired with a power supply and an external battery to achieve the backup function.The main function of DUPS20/40 is to monitor DC output voltage as well as to charge the battery to ensure the continuous operation of entire system (backup period depends on the load and battery capacity). When the AC mains fails or is interrupted, the load will be immediately connected to the battery pack to avoid...



Media Center

EV Charging Solutions

MEAN WELL power supplies for EV chargers include the board mount IRM series, the DIN Rail HDR series, the chassis mount UHP and HEP series. All four series provide reliable, fanless operation. Using convection or conduction cooling over a wide temperature range. The different series cover power range from 1W to 2300W, and the UHP and HEP series include high voltage output options. For more information, please refer to links below:
IRM series HDR series UHP series HEP series



DIN Rail Introduction: Why & How to Choose MEAN WELL DIN Rail PSU

MEAN WELL is an international well-known brand. It has more than 200 distribution channels worldwide and sold to more than 80 countries. The full product line of DIN rail power supplies covers from 10 to 960W, nearly 200 models, including AC/DC 1~3 phase input, DC-DC and various peripheral modules. It has been widely used in industrial control automation, building automation, information communication equipment, railway transportation... and other industries.

More Information



DIN Rail Type Product Line Introduction

The portfolio of MEAN WELL DIN rail power supply is complete, including AC/DC metal and plastic case design, DC/DC, and peripheral modules. On demand, you can buy easily through MEAN WELL branch offices and more than 200 distribution channels in more than 80 countries.



More Information

Solutions

MEAN WELL DRC-100 series, 100W DIN Rail Type Security Power Supply with UPS Function

MEAN WELL DRS-240/480 Series 240W / 480W All-in-One Intelligent Security Power Supply, bi-directional amplifier

MEAN WELL DRC-180 series, 180W DIN Rail Type Security Power Supply, security control system

MEAN WELL DUPS20/40 series, 20A/40A DIN Rail Type Uninterruptible DC-UPS Module, monitoring system in parking lot

MEAN WELL DDRH-60 series, 60W ultra wide input DIN rail type DC/DC converter
